Layer 3 functions
8.1 NAT
SCALANCE S615 Command Line Interface
292 Configuration Manual, 06/2015, C79000-G8976-C406-02
For information on identifiers of addresses and interfaces, refer to the section "Commands in
the FIREWALL NAT configuration mode (Page 288)".
Note
If the port is already occupied by a local service, for example Telnet,
a warning is displayed.
In this case, avoid using the following ports: TCP port 23 (Telnet), port 22 (SSH), the ports
80/443 (http/https: reachability of the client with the WBM), UDP port 161 (SNMP), port 500
(ISAKMP), port 4500 (IPsec Nat
-T).
The NAPT rule is created. During creation, an entry with a unique number (index) is created.
You delete a NAPT rule with the no napt command.
You delete all NAPT rules with the
no napt all command.
You display the numbers of the NAPT rules with the
napt show-idx command.
You display the NAPT rule with the
show firewallnat napt command.
With this command, you delete a specific NAPT rule.
● VLAN interface with subnet assignment
● You are in the FIREWALL NAT configuration mode.
The command prompt is as follows:
cli(config-fwnat)#
Call up the command with the following parameters:
no napt srcint <vlan> <num(0-4094)> idx <num(1-200)>
The parameters have the following meaning:
Keyword for the source interface
Type or speed of the interface
Specify a valid interface.
