Codes and scanning rules Instruction manual GLM-I
216 38.019.129.001 en
19
19.3.3 Edit and save code structure rule
Code editor is open.
Select and confirm code type, see page 213.
Enter and confirm module width and code height, see page 215.
If necessary, enter and confirm the ratio. The code type determines whether or not
you can enter the ratio, see page 215
.
Press <Code structure>.
The code structure editor appears.
Define part elements of code, see page 220.
Quit code structure editor with <Enter>.
Press <Special inputs>.
An input window appears, in which special settings can be made pertaining to the se-
lected code type.
Make the special inputs you want, see page 224.
Quit the input window via <Enter>.
Quit the code editor via <Enter>.
To save data reply to security query with <yes>.
Enter and confirm code structure number, see page 77.
The code structure rule is saved in the database under the entered code structure number.
