Setting display and keyboard layout Instruction manual GLM-I
92 38.019.129.001 en
8
Press softkey with respective setting.
8.5 Setting weight display
You may configure content and layout of large display (L2), see page 91. With setting
<Enlarged view
> you can define which data are to be viewed largely in a separate display
frame. The following settings are possible:
"No display": No separate display frame.
"Weight display": Large view of article weight.
"Device name": Large view of ID and device name.
"Mean value from n
weight values":
Large view of average weight value of a preset number of the
last weighed packages.
"Mean value of packages
checked":
Large view of average weight value of the packages checked
through statistics.
"Mean value of accept.
pckgs":
Large view of average weight value of the packages checked
and approved through statistics.
Mode level: 2
<Etc> / <Display> / <Etc> / <Enlarged view>
Select setting and confirm.
8.6 Setting text display
This settings defines the content and layout of the displayed text field. The text field is indi-
cated by all display formats
. Usually it contains the article text. The following texts can be
displayed in the text field:
– Article text
– Text fields 1 to 20
Mode level: 2
<Etc> / <Display> / <Text display> / <Text displ. TxtFld No.:>
Select setting and confirm.
This function <Select represent.> can be found on devices with color
screen without function.
8.7 Setting total display
With this function you may define if the total windows 1 to 3 are displayed and which con-
tent they have.
