31.2.2 Lateral package guidance
For lateral package guidance the alignment rail is pre-set and the alignment rail is set ac-
cordingly to the package width
.
Illustration 79: Lateral package guidance
When changing the package width the alignment rail B must be set.
Proceed as follows
:
Loosen star handles
1
.
Move alignment rail B by respective distance.
Tighten star handles
1
.
31.3 Motorized guide rails
The device may be equipped with motorized guide rails. They allow easy and fast adjust-
ment of the alignment rails to the respective aperture width according to different package
or article sizes.
31.3.1 Switching on/off motorized guide rails
The following settings are possible:
–
"W/o"
– "With"
Mode level: 5
<Automat> / <Optional equipment> / <Powered guide rails>
Tap the softkey until the required setting is highlighted.
