Instruction manual GLM-I Back up data

38.019.129.001 en 367

27.1.2 Saving line backup

In the case of a line with several devices you can save the data from all devices in one

work step. The system bus address of the devices may not be subsequently modified.

Macros saved with the display and operating unit GT-12 C, the GT-12 C

saves and not the device. Therefore these macros are missing in a line

back-up of the device.

Requirements:

–

The devices that belong to the line are defined, see page 371.

– The devices are connected with each other via the system bus.

– The devices are switched on.

– Mode level: 5

Make sure that the storage medium is inserted in device.

Enter the name of the data backup. Comply with the rules for DOS file names.

Press <ok>.

A table occurs. The table columns contain the devices that belong to the line. The ta-

ble rows contain different data groups

. You can select the device from which you want

to save data. Non-existing data groups cannot be selected.

Select data

Select or deselect a data group for each device: Touch the table field until the re-

quired setting occurs

Select all data groups for a device: Select the table head of the device. Press <Set>

in the following inquiry

Deselect all data groups for a device: Select the table head of the device. Press

<Delete> in the following inquiry

Select a data group for all devices: Select the data group in the left table column.

Press <Set> in the following inquiry

Deselect a data group for all devices: Select the data group in the left table column.

Press <Delete> in the following inquiry

Select all: Select the left table field in the table header. Press <Set> in the following

inquiry.

Deselect all: Select the left table field in the table header. Press <Delete> in the fol-

lowing inquiry
