Bizerba GLM-I - Compressed Air Supply

Technical data Instruction manual GLM-I
464 38.019.129.001 en
32
Labeler Printer Label width x label height [mm]
D x E
Comment
minimum max. with
labeler 80
max. with
labeler 160
Piston labeler Platen
Printer,
EcoMotion
Printer
40 x 40 86 x 100 100 x 100
Rotary arm la-
beler
Platen
Printer
30 x 20
30 x 38
80 x 45
86 x 100
80 x 45
100 x 100
Belt labeler Platen
Printer,
EcoMotion
Printer
40 x 40 — 168 x 150
Thermal transfer roll
Core diameter A 25,4 + 0,3 mm
Outer diameter B max. 81 mm
Roll width D 32,5 - 122,5 mm
32.3 Compressed air supply
For operating air-jet, piston and belt labelers a customer-sided supply with oil-free com-
pressed air is required.
Supply: DIN/ISO 8573-1, class 3
Air pressure min.: 6 bar
Conditioning: oil-free (filtered for devices without fine filter, 10 µm particle
size)
Connector: 9 mm (inner diameter of tube, calibrated inside)
Labeler Air consumption
Label length/mm Printing speed (mm/s):
m
3
/1000 labels
Air-jet labeler 50 250 1,3
150 250 1,9
Piston labeler 50 250 0,8
150 250 1,3
Belt labeler independent independent 0,7
