Instruction manual GLM-I Codes and scanning rules
38.019.129.001 en 237
19
19.7.7 Enter code structure rule SGTIN-96 (example)
The example shows how to create an SGTIN-96 with the following code structure:
Code part Decimal Binary Hex max. bits
Header 96 01100000 60 8 Bits
Filter val-
ue
3 011 3 3 Bits
Partition 5 101 5 3 Bits
Company
prefix
0614141 0000 1001 0101 1110 1111 1101 095efd 24 Bits
Subdivision
according to
partition
20 Bits
Item refer-
ence
000734 0000 0000 0010 1101 1110 002de
Serial
number
203886 00 0000 0000 0000 0000 0011
0001 1100 0110 1110
0000031c6e 38 Bits
96 Bits
Data for transponder in bits: 01100000 011 101
/0000 1001 0101 1110 1111 1101/0000
0000 0010 1101 1110/00 0000 0000 0000 0000 0011 0001 1100 0110 1110
Code editor is open.
Select code "EPC-96"type.
Press <Code structure>.
Header: Select and confirm under "Gen. code contents
" "HEX constant". Enter and
confirm hexadecimal value, "60".
Filter value: Select and confirm under "Gen. code contents
" "Bin constant". Enter and
confirm binary value, "011".
Partition: Select and confirm under "Gen. code contents
" "Bin constant". Enter and
confirm the binary value "101" as the specification for separation.
Company prefix: Select and confirm under "Gen. code contents
" "HEX constant".
Enter the hexadecimal value of "095efd" as the manufacturer number.
Item reference: Select and confirm under "Gen. code contents" "Code substring1".
Enter and confirm 20 bits as number of digits for PLU numbers. Company prefix and
item reference may not exceed 44 bits.
Serial number: Select under "Gen. code contents" "Numerator
". Enter and confirm
38 bits as the number of digits.
Press <Enter>.
Press <Enter> again.
To save Code structure rule reply to security query with <yes>.
Enter and confirm code structure number, see page 77.
The code structure rule is saved in the database under the entered number.
