Bizerba GLM-I User Manual

Accessories Instruction manual GLM-I
456 38.019.129.001 en
31
31.15 Code checker
WARNING Code checkers use laser beams.
Risk of injuries to the eyes.
–
Do not look directly into the laser beam.
– Avoid reflection from laser beams on reflecting surfaces (e.g.
watch, jewelry).
If the device is provided with one or more code checkers for checking the label codes, the
following settings can be made for each code checker
:
– Packages to be checked, see page 457
– Evaluation time, see page 457
– Gate width, see page 457
– Gate offset, see page 457
Illustration 105: Code checker settings
1
Gate width
2
Gate offset
3
Light barrier
4
Code checker (scanner)
5
Conveying direction
Example: Code checker 1. The procedure for code checkers 2 and 3 is the same.
