Technical data Instruction manual GLM-I
468 38.019.129.001 en
32
Interfaces on GT-12C
System bus SB:
for connection to Bizerba system network, connector: D-Sub 9-
pin (socket).
EDP 1: for software download, RS232, RS422, TTY, connector: D-Sub
9-pin (socket).
Ethernet: Connector: 10 base T, TCP/IP
32.10 Scale data
The technical data depend on the scale installed and are displayed on the verification
screen of the display.
Please write the displayed value into the table mentioned below
, in order to access this
date in case of device failure.
Max 1. Weighing range:
2. Weighing range:
Min.
e 1. Weighing range:
2. Weighing range
:
32.11 Package dimensions
The package height depends on the light barrier design at the conveyor belt.
Length Width Height
GLM-I 40 1T min.: 250 mm
max. 800 mm
min.: 50 mm
max. 600 mm
min.: 10 mm
max. 250 mm
GLM-I 40 1S min.: 250 mm
max. 800 mm
min.: 50 mm
max. 600 mm
min.: 10 mm
max. 600 mm
GLM-I
70/100/150/170
min.: 40 mm
max. 700 mm
1)
min.: 25 mm
max. 400 mm
2)
min.: 1 mm
max. 350 mm
1)
Depending on length of weighing belt
.
2)
Depending on width of weighing belt
The minimum package height of 1 mm is only possible with an oblique
or vertical light barrier.
