Instruction manual GLM-I Labeling systems
38.019.129.001 en 55
6
6.8 Labeling from bottom with belt labeler
The belt labeler can be pulled out from the transport rack if required. This is necessary if
air supply for the grippers needs to be adjusted for other label sizes or if the label roll is
located on the back during assembly.
Pull labeler out
Illustration 21: Retaining plate
Pull entire labeler out of conveyor frame
at retaining plate
4
.
Turn labeler for label roll change
To change the label roll, turn the labeler until the label roll can be easily accessed.
Change label roll
The label roll is changed in analog to master labeler, see page 58.
Return labeler to basic position
Turn the labeler back and push it into the conveyor frame until you feel it engaged.
