Bizerba GLM-I - Printer

Technical data Instruction manual GLM-I
462 38.019.129.001 en
32
32.2 Printer
The labeler can be equipped with a 80 mm or a 160 mm thermal or thermal transfer print-
er. Depending on the printer version there are two differently wide labeler housings.
Printer version 80 mm 160 mm
Resolution 8 Dot/mm:
Print width / Number of
dots
80 mm (3") / 640 Dot
56 mm (2") / 448 Dot
160 mm (6") / 1280 Dot
104 mm (4") / 832 Dot
80 mm (3") / 640 Dot
56 mm (2") / 448 Dot
Resolution 12 Dot/mm:
Print width / number of
dots
80 mm (3") / 960 Dot 160 mm (6") / 1920 Dot
104 mm (4") / 1248 Dot
80 mm (3") / 960 Dot
Printing process Thermal direct, optionally thermal transfer
Printing speed 150 mm/s, optional 250 mm/s; depending on printing width and
resolution
Label output Upper print image, adhesive side at bottom
Label output Automatic application of label on package with air-jet, rotary
arm, piston or belt labeler
.
