Accessories Instruction manual GLM-I
430 38.019.129.001 en
31
31.5.1 Package ejector description
The flaps of the package ejector that are provided with transport rollers are controlled
pneumatically by means of compressed air cylinders
. For this reason, the package ejector
is connected to the compressed air supply of the device. The permissible max. force at the
flaps of the package ejector is 75 N.
Illustration 83: View: package ejector
31.5.2 Maximum package size
The open flaps of the package ejector have a clearance height of approx. 190 mm and a
clear width of approx. 300 mm. Thus, packages with maximum dimensions up to the said
ones can be ejected in a safe and reliable way.
Package height Package width Package length
180 mm 300 mm 500 mm
