Instruction manual GLM-I Accessories
38.019.129.001 en 445
31
31.10.7 Calling up saved label settings
Saved label settings can be called up at any time.
By pressing the <UP> or <DOWN> keys,
call up the "CALL NO." parameter. Call the
next label number using the
<+> key or the
previous label number using the <->key.
Save input using the <MODE – ENTER>
key.
Illustration 104: Call up label settings
31.10.8 Cleaning and maintenance
Daily
1. If required, clean drums and rollers and remove glue and label residues.
2. Clean light barrier and remove dust and glue residues.
Clean light barrier where the label strip passes. Remove dust and label residues es-
pecially from the two small holes that are located at approx. 10 mm from the edge.
Use only the recommended cleaning fluid SOLVO KLEEN for cleaning.
Weekly
Remove glue and label residues from all drums and rollers
. Moreover, remove dust and
any kind of soiling from the complete label dispenser.
