Instruction manual GLM-I Back up data
38.019.129.001 en 373
27
27.3.1 Save setup
Mode level: 5
<Setup> / <Create setup>
Enter name of setup. The name can be a maximum of four characters, e. g. SET1.
Take note of large and small case
.
Press <ok>.
If no setup is saved under the same name and if there have not been saved three set-
ups yet, the new setup is saved immediately
.
If a setup has already been saved with the same name, this message appears: "Set-
up name existing.Select new name.".
If three setups have already been saved, the following message appears: "No more
free capacity for setup.". In order to save a new setup, an old setup needs to be de-
leted, see page 374.
If need be, confirm message with <ok>.
The data are not saved.
27.3.2 Activate setup
Stored setups can be activated at any time. Plan carefully with which setup you want to
change the data of the device
.
The @INI setup contains the works settings of the device and is always included in a data
backup. The @SAV setup is produced during the first line backup. With each additional
line backup, @SAV is updated.
An imported setup cannot be activated until the device has been switch-
ed off and on again.
Mode level: 5
<Setup> / <Activate setup>
Select a setup and press <ok>.
The following message appears: "Important data modification: Process can only be
done after switch on/off of device.".
Press <ok>.
Switch device off and on.
The new setup is active after a restart.
