Codes and scanning rules Instruction manual GLM-I

230 38.019.129.001 en

19.6.4 Print sub-code string: Explanations

In additional code number fields on customer labels, you can print a code string or selec-

ted parts of a code string separately. The license "CODE_PART_PRINT" is required for

separate printing. The following settings are possible:

<Part code str.1>: If only part of the code strings should be printed, enter the start

and end of the range to be printed here. Start and end refer to

the code contents (see example below).

<Space part1>: – "With" set this if you want spaces to be set between the se-

lected code contents.

– Set "W/o" if you want the code content to be printed with-

out space as separator.

<AI part1>: Only for GS1-128.

– "With" set this if you want the AI numbers to be printed in

the code number field. Standard setting.

– "W/o" set this if you don't want the AI numbers to be prin-

ted in the code number field.

Example of defining a section

Code structure

Code substring{12-digit} Price{5 digits, dec. place int} Numerator{6 digits}

1st content 2nd content 3rd content

In order to print part of a code string with the second and third code content, enter

"Start"=2 and "End"=3. To print the complete code string, you don't need to enter anything

at all here.

Speciality of EAN13 and EAN8 code

If, with these code types, you are working with the "XXXXXP.6.", "XXXXXXP.5." etc. for-

mats, the middle check digit is valued as own code content.

Example:

Code structure

Code substring{xxxxxP.5} Price{5 digits, dec. place int}

string Middle check digit Price Symbol for check

digit

1st content 2nd content 3rd content 4th content

To print part of a code string with the middle check digit, price and symbol for the check

digit, enter "Start"=2 and "End"=4.
