To enable low power mode wakeup (SLEEP, DEEPSLEEP and BACKUP) using an external GPIO interrupt, complete the

following steps:

1. Clear pending interrupt flags by writing to GPIOn_INT_CLR[pin].

2. Activate the GPIO wakeup function by writing 1 to GPIOn_WAKE_EN[pin].

3. Configure the power manager to use the GPIO as a wakeup source by setting the appropriate .gpiowken field to 1.

6.4 Registers

Each GPIO port has a unique base address as shown in Table 3-1: APB Register Base Address Map. Unless specified

otherwise, all fields are reset on a system reset, soft reset, POR, and the peripheral-specific reset, if applicable.

Table 6-8: GPIO Register Summary

Offset

Name

[0x0000]

GPIOn_EN0

GPIO Port n Configuration Enable Bit 0 Register

[0x0004]

GPIOn_EN0_SET

Atomic set for GPIOn_EN0 register

[0x0008]

GPIOn_EN0_CLR

Atomic clear for for GPIOn_EN0 register

[0x000C]

GPIOn_OUT_EN

GPIO Port n Output enable register

[0x0010]

GPIOn_OUT_EN_SET

Atomic set for GPIOn_OUT_EN register

[0x0014]

GPIOn_OUT_EN_CLR

Atomic clear for GPIOn_OUT_EN register

[0x0018]

GPIOn_OUT

GPIO Port n Output register

[0x001C]

GPIOn_OUT_SET

Atomic set for GPIOn_OUT register

[0x0020]

GPIOn_OUT_CLR

Atomic clear for GPIOn_OUT register

[0x0024]

GPIOn_IN

GPIO Port n Input register

[0x0028]

GPIOn_INT_MODE

GPIO Port n Interrupt mode register

[0x002C]

GPIOn_INT_POL

GPIO Port n Interrupt polarity register

[0x0030]

GPIOn_IN_EN

GPIO Port n Input enable register

[0x0034]

GPIOn_INT_EN

GPIO Port n Interrupt enable register

[0x0038]

GPIOn_INT_EN_SET

Atomic set for GPIOn_INT_EN register

[0x003C]

GPIOn_INT_EN_CLR

Atomic clear for GPIOn_INT_EN register

[0x0040]

GPIOn_INT_STAT

GPIO Port n Interrupt status register

[0x0048]

GPIOn_INT_CLR

Atomic clear for GPIOn_INT_STAT register

[0x004C]

GPIOn_WAKE_EN

GPIO Port n Wake from DEEPSLEEP enable register

[0x0050]

GPIOn_WAKE_EN_SET

Atomic set for GPIOn_WAKE_EN register

[0x0054]

GPIOn_WAKE_EN_CLR

Atomic clear for GPIOn_WAKE_EN register

[0x005C]

GPIOn_INT_DUAL_EDGE

GPIO Port n Interrupt dual edge register

[0x0060]

GPIOn_PDPU_SEL0

GPIO Port n Input mode selection register 0

[0x0064]

GPIOn_PDPU_SEL1

GPIO Port n Input mode selection register 1

[0x0068]

GPIOn_EN1

GPIO Port n Configuration Enable Bit 1 Register

[0x006C]

GPIOn_EN1_SET

Atomic Set for GPIOn_EN1 register

[0x0070]

GPIOn_EN1_CLR

Atomic Clear for GPIOn_EN1 register

[0x0074]

GPIOn_EN2

GPIO Port n Configuration Enable Bit 2 Register

[0x0078]

GPIOn_EN2_SET

Atomic Set for GPIOn_EN2 register

[0x007C]

GPIOn_EN2_CLR

Atomic Clear for GPIOn_EN0 register

[0x00B0]

GPIOn_DS_SEL0

GPIO Port n Output Drive strength selection register 0
