MAX32665-MAX32668 User Guide

Maxim Integrated Page 237 of 457

Table 9-18: DMA Channel n Count Reload Register

DMA Count Reload

DMAn_CNT_RLD

[0x011C]

Bits

Field

Access

Reset

Description

rlden

R/W

Reload Enable.

Enables automatic loading of the DMACHn_SRC, DMACHn_DST, and

DMACHn_CNT registers when a CTZ event occurs. Set this bit after the

address reload registers are programmed.

Note: This bit is automatically cleared to 0 when reload occurs.

Note: This bit is also seen in the DMACHn_CFG register.

0: Reload disabled

1: Reload enabled

30:24

Reserved

23:0

cnt_rld

R/W

Count Reload Value.

If DMAn_CNT_RLD.rlden = 1, then the value of this register is loaded into

DMACHn_CNT upon a CTZ condition.
