MAX32665-MAX32668 User Guide
Maxim Integrated Page 356 of 457
Table 17-3: Pulse Train Engine Resync Register
PT Resync Register
PTG_RESYNC
[0x0004]
Bits
Field
Access
Reset
Description
31:16
-
RO
0
Reserved for Future Use
Do not modify this field from its default value.
15
pt15
WO
-
Resync Control for PT15
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
14
pt14
WO
-
Resync Control for PT14
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
13
pt13
WO
-
Resync Control for PT13
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
12
pt12
WO
-
Resync Control for PT12
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
11
pt11
WO
-
Resync Control for PT11
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
