MAX32665-MAX32668 User Guide
Maxim Integrated Page 69 of 457
Error Correction Coding Enable
MCR_ECCEN
[0x0000]
Bits
Field
Access
Reset
Description
7:6
-
RO
0
Reserved
Do not modify this field.
5
sysram5eccen
R/W
0
Sysram5 ECC Enable
0: Disable
1: Enable
4
sysram4eccen
R/W
0
Sysram4 ECC Enable
0: Disable
1: Enable
3
sysram3eccen
R/W
0
Sysram3 ECC Enable
0: Disable
1: Enable
2
sysram2eccen
R/W
0
Sysram2 ECC Enable
0: Disable
1: Enable
1
sysram1eccen
R/W
0
Sysram1 ECC Enable
0: Disable
1: Enable
0
Sysram0eccen
R/W
0
Sysram0 ECC Enable
0: Disable
1: Enable
Table 4-16: SQWOUT and PDOWN Output Enable Register
SQWOUT/PDOWN Output Enable
MCR_OUTEN
[0x0008]
Bits
Field
Access
Reset
Description
31:4
-
RO
0
Reserved
Do not modify this field.
3
pdownout1en
R/W
0
PDOWN Enable P0.26
0: GPIO function on pin.
1: PDOWN signal on pin if PWRSEQ_LPCN.pdowndslen = 1.
2
pdownout0en
R/W
0
PDOWN Enable P0.18
0: GPIO function on pin.
1: PDOWN signal on pin if PWRSEQ_LPCN.pdowndslen = 1.
1
sqwout1en
R/W
0
SQWOUT Enable P0.27
0: GPIO function on pin.
1: SQWOUT signal on pin.
0
sqwout0en
R/W
0
SQWOUT Enable P0.19
0: GPIO function on pin.
1: SQWOUT signal on pin.
Table 4-17: Comparator Enable Register
Comparator Enable
MCR_AINCOMP
[0x000C]
Bits
Field
Access
Reset
Description
31:6
-
RO
0
Reserved
Do not modify this field.
5:4
aincomphyst
R/W
0
Comparator Hysteresis Control
Refer to the V
HYST
specification in the data sheet electrical characteristics for the
values corresponding to this field value.
