MAX32665-MAX32668 User Guide
Maxim Integrated Page 364 of 457
Pulse Train Engine Safe Enable Register
PTG_SAFE_EN
[0x0010]
Bits
Field
Access
Reset
Description
6
safeen_pt6
WO
-
Safe Enable Control for PT6
Writing a 1 sets PTG_ENABLE.enable_pt6.
1: Enable corresponding pulse train
0: No effect
5
safeen_pt5
WO
-
Safe Enable Control for PT5
Writing a 1 sets PTG_ENABLE.enable_pt5.
1: Enable corresponding pulse train
0: No effect
4
safeen_pt4
WO
-
Safe Enable Control for PT4
Writing a 1 sets PTG_ENABLE.enable_pt4.
1: Enable corresponding pulse train
0: No effect
3
safeen_pt3
WO
-
Safe Enable Control for PT3
Writing a 1 sets PTG_ENABLE.enable_pt3.
1: Enable corresponding pulse train
0: No effect
2
safeen_pt2
WO
-
Safe Enable Control for PT2
Writing a 1 sets PTG_ENABLE.enable_pt2.
1: Enable corresponding pulse train
0: No effect
1
safeen_pt1
WO
-
Safe Enable Control for PT1
Writing a 1 sets PTG_ENABLE.enable_pt1.
1: Enable corresponding pulse train
0: No effect
0
safeen_pt0
WO
-
Safe Enable Control for PT0
Writing a 1 sets PTG_ENABLE.enable_pt0.
1: Enable corresponding pulse train
0: No effect
17.9.2 Pulse Train Engine Safe Disable Register
A 32-bit value written to this register immediately disables the corresponding pulse train in the PTG_ENABLE register. The
result is immediately stored in PTG_ENABLE. Setting a field to 1 disables the corresponding pulse train immediately.
Table 17-7: Pulse Train Engine Safe Disable Register
Pulse Train Engine Safe Disable Register
PTG_SAFE_DIS
[0x0014]
Bits
Field
Access
Reset
Description
31:16
-
RO
0
Reserved for Future Use
Do not modify this field from its default value.
15
safedis_pt15
WO
-
Safe Disable Control for PT15
Writing a 1 clears PTG_ENABLE.enable_pt15.
1: Disable corresponding pulse train
0: No effect
14
safedis_pt14
WO
-
Safe Disable Control for PT14
Writing a 1 clears PTG_ENABLE.enable_pt14.
1: Disable corresponding pulse train
0: No effect
