Maxim Integrated MAX32665 User Manual

MAX32665-MAX32668 User Guide
Maxim Integrated Page 365 of 457
Pulse Train Engine Safe Disable Register
PTG_SAFE_DIS
[0x0014]
Bits
Field
Access
Reset
Description
13
safedis_pt13
WO
-
Safe Disable Control for PT1
Writing a 1 clears PTG_ENABLE.enable_pt13.
1: Disable corresponding pulse train
0: No effect
12
safedis_pt12
WO
-
Safe Disable Control for PT12
Writing a 1 clears PTG_ENABLE.enable_pt12.
1: Disable corresponding pulse train
0: No effect
11
safedis_pt11
WO
-
Safe Disable Control for PT11
Writing a 1 clears PTG_ENABLE.enable_pt11.
1: Disable corresponding pulse train
0: No effect
10
safedis_pt10
WO
-
Safe Disable Control for PT10
Writing a 1 clears PTG_ENABLE.enable_pt10.
1: Disable corresponding pulse train
0: No effect
9
safedis_pt9
WO
-
Safe Disable Control for PT9
Writing a 1 clears PTG_ENABLE.enable_pt9.
1: Disable corresponding pulse train
0: No effect
8
safedis_pt8
WO
-
Safe Disable Control for PT8
Writing a 1 clears PTG_ENABLE.enable_pt8.
1: Disable corresponding pulse train
0: No effect
7
safedis_pt7
WO
-
Safe Disable Control for PT7
Writing a 1 clears PTG_ENABLE.enable_pt7.
1: Disable corresponding pulse train
0: No effect
6
safedis_pt6
WO
-
Safe Disable Control for PT6
Writing a 1 clears PTG_ENABLE.enable_pt6.
1: Disable corresponding pulse train
0: No effect
5
safedis_pt5
WO
-
Safe Disable Control for PT5
Writing a 1 clears PTG_ENABLE.enable_pt5.
1: Disable corresponding pulse train
0: No effect
4
safedis_pt4
WO
-
Safe Disable Control for PT4
Writing a 1 clears PTG_ENABLE.enable_pt4.
1: Disable corresponding pulse train
0: No effect
3
safedis_pt3
WO
-
Safe Disable Control for PT3
Writing a 1 clears PTG_ENABLE.enable_pt3.
1: Disable corresponding pulse train
0: No effect
