Table 3-5: Correctable Error Detected Register
Correctable Error Detected
GCR_ECC_CED
[0x0068]
Bits
Field
Access
Reset
Description
31:13
-
RO
0
Reserved for Future Use
Do not modify this field.
12
fl1eccnded
R/W1C
0
ECC Flash1 Correctable Error Detected
Indicates a single bit correctable error in the Flash1 bank. Write to 1 to clear.
0: No single bit error detected
1: Correctable
11
fl0eccnded
R/W1C
0
ECC Flash0 Correctable Error Detected
Indicates a single bit correctable error in the Flash0 bank. Write to 1 to clear.
0: No single bit error detected
1: Correctable
10
icspixfeccnded
R/W1C
0
ECC SPIXF Correctable Error Detected
Indicates a single bit correctable error in SPIXF Instruction Cache. Write to 1 to
clear.
0: No single bit error detected
1: Correctable
9
ic1eccnded
R/W1C
0
ECC Instruction Cache 1 Correctable Error Detected
Indicates a single bit correctable error in Instruction Cache 1. Write to 1 to clear.
0: No single bit error detected
1: Correctable
8
ic0eccnded
R/W1C
0
ECC Instruction Cache 0 Correctable Error Detected
Indicates a single bit correctable error in Instruction Cache 0. Write to 1 to clear.
0: No single bit error detected
1: Correctable
7
-
RO
0
Reserved for Future Use
Do not modify this field.
6
-
RO
0
Reserved for Future Use
Do not modify this field.
5
sysram5ecc_ced
R/W1C
0
ECC Sysram5 Correctable Error Detected
Indicates a single bit correctable error in the Sysram5 block. Write to 1 to clear.
0: No single bit error detected
1: Correctable
4
sysram4ecc_ced
R/W1C
0
ECC Sysram4 Correctable Error Detected
Indicates a single bit correctable error in the Sysram 4 block. Write to 1 to clear.
0: No single bit error detected
1: Correctable
3
sysram3ecc_ced
R/W1C
0
ECC Sysram3 Correctable Error Detected
Indicates a single bit correctable error in the Sysram 3 block. Write to 1 to clear.
0: No single bit error detected
1: Correctable
2
sysram2ecc_ced
R/W1C
0
ECC Sysram2 Correctable Error Detected
Indicates a single bit correctable error in the Sysram 2 block. Write to 1 to clear.
0: No single bit error detected
1: Correctable
