Maxim Integrated MAX32665 - Register Details; Table 17-2: Pulse Train Engine Global Enable;Disable Register

MAX32665-MAX32668 User Guide
Maxim Integrated Page 354 of 457
Offset
Register
Description
[0x00F0]
PTn_RATE_LENGTH
PT13 Configuration
[0x00F4]
PTn_TRAIN
PT13 Pulse Train Mode Bit Pattern
[0x00F8]
PTn_LOOP
PT13 Loop Control
[0x00FC]
PTn_RESTART
PT13 Automatic Restart
[0x0100]
PTn_RATE_LENGTH
PT14 Configuration
[0x0104]
PTn_TRAIN
PT14 Pulse Train Mode Bit Pattern
[0x0108]
PTn_LOOP
PT14 Loop Control
[0x010C]
PTn_RESTART
PT14 Automatic Restart
[0x0110]
PTn_RATE_LENGTH
PT15 Configuration
[0x0114]
PTn_TRAIN
PT15 Pulse Train Mode Bit Pattern
[0x0118]
PTn_LOOP
PT15 Loop Control
[0x011C]
PTn_RESTART
PT15 Automatic Restart
17.9 Register Details
Table 17-2: Pulse Train Engine Global Enable/Disable Register
PT Global Enable/Disable Control
PTG_ENABLE
[0x0000]
Bits
Field
Access
Reset
Description
31:16
-
RO
0
Reserved for Future Use
Do not modify this field from its default value.
15
enable_pt15
R/W
0
Enable PT15
0: Disable
1: Enable
Note: Disabling an active pulse train halts the output and does not generate a Stop Event.
14
enable_pt14
R/W
0
Enable PT14
0: Disable
1: Enable
Note: Disabling an active pulse train halts the output and does not generate a Stop Event.
13
enable_pt13
R/W
0
Enable PT13
0: Disable
1: Enable
Note: Disabling an active pulse train halts the output and does not generate a Stop Event.
12
enable_pt12
R/W
0
Enable PT12
0: Disable
1: Enable
Note: Disabling an active pulse train halts the output and does not generate a Stop Event.
11
enable_pt11
R/W
0
Enable PT11
0: Disable
1: Enable
Note: Disabling an active pulse train halts the output and does not generate a Stop
Event.
10
enable_pt10
R/W
0
Enable PT10
0: Disable
1: Enable
Note: Disabling an active pulse train halts the output and does not generate a Stop Event.
