Maxim Integrated Page 322 of 457
QSPIn Interrupt Enable Register
QSPIn_INT_EN
[0x0024]
Bits
Name
Access
Reset
Description
9
abort
R/W
0
Slave Mode Abort Detected Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
8
fault
R/W
0
Multi-Master Fault Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
7:6
-
R/W
0
Reserved for Future Use
Do not modify this field.
5
ssd
R/W
0
Slave Select Deasserted Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
4
ssa
R/W
0
Slave Select Asserted Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
3
rx_full
R/W
0
RX FIFO Full Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
2
rx_thresh
R/W
0
RX FIFO Threshold Level Crossed Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
1
tx_empty
R/W
0
TX FIFO Empty Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
0
tx_thresh
R/W
0
TX FIFO Threshold Level Crossed Interrupt Enable
0: Interrupt is disabled
1: Interrupt is enabled
Table 14-16: QSPIn Wakeup Status Flags Registers
QSPIn Wakeup Flags Register
QSPIn_WAKE_FL
[0x0028]
Bits
Name
Access
Reset
Description
31:4
-
R/W
0
Reserved for Future Use
Do not modify this field.
3
rx_full
R/W1C
0
Wake on RX FIFO Full Flag
0: Wake condition has not occurred.
1: Wake condition occurred.
2
rx_thresh
R/W1C
0
Wake on RX FIFO Threshold Level Crossed Flag
0: Wake condition has not occurred.
1: Wake condition occurred.
1
tx_empty
R/W1C
0
Wake on TX FIFO Empty Flag
0: Wake condition has not occurred.
1: Wake condition occurred.
0
tx_thresh
R/W1C
0
Wake on TX FIFO Threshold Level Crossed Flag
0: Wake condition has not occurred.
1: Wake condition occurred.
