MAX32665-MAX32668 User Guide

Maxim Integrated Page 386 of 457

Table 19-4: Watchdog Timer Reset Register

Watchdog Timer Reset Register

WDTn_RST

[0x0004]

Bits

Access

Reset

Description

31:8

Reserved for Future Use

Do not modify this field from its reset value.

7:0

wdt_rst

R/W

Reset Register

Writing the watchdog counter reset sequence to this register resets the

watchdog counter. The following is the required reset sequence to reset the

watchdog and prevent a watchdog timer interrupt or watchdog system reset.

This field is set to 0 on a POR and is not affected by other resets.

• Write WDTn_RST: 0x000000A5

• Write WDTn_RST: 0x0000005A
