SPIXR Slave Select Timing Register
Slave Select Active After Last SCK
Number of system clock cycles that SS is active from the last SCK edge to when
SS is inactive.
Slave Select Active Before SCK
Number of system clock cycles between the time SS is asserted until the first SCK
edge.
Table 8-30. SPIXR Master Baud Rate Generator
SPIXR Master Baud Rate Generator Register
Reserved for Future Use
Do not modify this field.
System Clock to SPIXR Clock Scale Factor
Scales the system clock by 2scale to generate the internal SPIXR peripheral
clock.
SCK Hi Clock Cycles Control
Setting this field to 0 disables the high duty cycle control for SCK.
Setting this field to any non-zero value sets the high cycle time to:
Note: If SPIXR_BRG_CTRL.scale = 0, SPIXR_BRG_CTRL.hi = 0, and
SPIXR_BRG_CTRL.lo = 0, character sizes of 2 and 10 bits are not supported.
