MAX32665-MAX32668 User Guide
Maxim Integrated Page 191 of 457
Table 8-53: Relationship between Parameters and the Name of Response Type
Response Type
SDHC_CMD.resp_type
Index Check Enable
SDHC_CMD.idx_chk_en
CRC Check Enable
SDHC_CMD.crc_chk_en
Table 8-54: SDHC Response 0 Register
Response Register 0
Response 7 to Response 0 registers are referenced as a contiguous, single register in
the SD Host Controller Spec V3.0. Table 8-62 shows the mapping from the Response
Registers to the SD Host Controller Standard Specification REP[127:0] notation for the
MAX32665—MAX32668. Table 8-63 shows the SD types of response mapped to the
MAX32665—MAX32668 Response registers.
Table 8-55: SDHC Response 1 Register
Response Register 1
Response 7 to Response 0 registers are referenced as a contiguous, single register in
the SD Host Controller Spec V3.0. Table 8-62 shows the mapping from the Response
Registers to the SD Host Controller Standard Specification REP[127:0] notation for the
MAX32665—MAX32668. Table 8-63 shows the SD types of response mapped to the
MAX32665—MAX32668 Response registers.
Table 8-56: SDHC Response 2 Register
Response Register 2
Response 7 to Response 0 registers are referenced as a contiguous, single register in
the SD Host Controller Spec V3.0. Table 8-62 shows the mapping from the Response
Registers to the SD Host Controller Standard Specification REP[127:0] notation for the
MAX32665—MAX32668. Table 8-63 shows the SD types of response mapped to the
MAX32665—MAX32668 Response registers.
