MAX32665-MAX32668 User Guide

Maxim Integrated Page 185 of 457

SDMA Command

ADMA Command

CPU Data Transfer

Non-DAT (No Data) Transfer

Argument 2

SDHC_SDMA

Yes

No (Protected)

Command

SDHC_CMD

Yes

8.5.5 SDHC Registers

See Table 3-1: APB Peripheral Base Address Map for the SDHC Peripheral Base Address

Table 8-45: SDHC Register Offsets, Names and Descriptions

Offset

Description

[0x0000]

SDHC_SDMA

SDMA System Address / Argument 2

[0x0004]

SDHC_BLK_SIZE

Block Size register

[0x0006]

SDHC_BLK_CNT

Block Count register

[0x0008]

SDHC_ARG_1

Argument 1 register

[0x000C]

SDHC_TRANS

Transfer Mode register

[0x000E]

SDHC_CMD

Command register

[0x0010]

SDHC_RESP_0

Response register 0

[0x0012]

SDHC_RESP_1

Response register 1

[0x0014]

SDHC_RESP_2

Response register 2

[0x0016]

SDHC_RESP_3

Response register 3

[0x0018]

SDHC_RESP_4

Response register 4

[0x001A]

SDHC_RESP_5

Response register 5

[0x001C]

SDHC_RESP_6

Response register 6

[0x001E]

SDHC_RESP_7

Response register 7

[0x0020]

SDHC_BUFFER

Buffer Data Port register

[0x0024]

SDHC_PRESENT

Present State register

[0x0028]

SDHC_HOST_CN_1

Host Control 1 register

[0x0029]

SDHC_PWR

Power Control register

[0x002A]

SDHC_BLK_GAP

Block Gap Control register

[0x002B]

SDHC_WAKEUP

Wakeup Control register

[0x002C]

SDHC_CLK_CN

Clock Control register

[0x002E]

SDHC_TO

Timeout Control register

[0x002F]

SDHC_SW_RESET

Software Reset register

[0x0030]

SDHC_INT_STAT

Normal Interrupt Status register

[0x0032]

SDHC_ER_INT_STAT

Error Interrupt Status register

[0x0034]

SDHC_INT_EN

Normal Interrupt Status Enable register

[0x0036]

SDHC_ER_INT_EN

Error Interrupt Status Enable register

[0x0038]

SDHC_INT_SIGNAL

Normal Interrupt Signal Enable register

[0x003A]

SDHC_ER_INT_SIGNAL

Error Interrupt Signal Enable register

[0x003C]

SDHC_AUTO_CMD_ER

Auto CMD Error Status register

[0x003E]

SDHC_HOST_CN_2

Host Control 2 register

[0x0040]

SDHC_CFG_0

Capabilities register 0

[0x0044]

SDHC_CFG_1

Capabilities register 1

[0x0048]

SDHC_MAX_CURR_CFG

Maximum Current Capabilities register
