MAX32665-MAX32668 User Guide
Maxim Integrated Page 216 of 457
Table 8-85: SDHC Maximum Current Capabilities Register
Maximum Current Capabilities Register
SDHC_MAX_CURR_CFG
[0x0048]
Bits
Name
Access
Reset
Description
31:24
-
RO
0
Reserved for Future Use
Do not modify this field.
23:16
1_8v
RO
0
Maximum Current for 1.8V
0x00: System dependent
15:8
3_0v
RO
0
Maximum Current for 3.0V
0x00: System dependent
7:0
3_3v
RO
0
Maximum Current for 3.3V
0x00: System dependent
Table 8-86: SDHC Force Event Register for Auto CMD Error Status Register
Force Event Register for Auto CMD Error Status
SDHC_FORCE_CMD
[0x0050]
Bits
Name
Access
Reset
Description
15:8
-
WO
0
Reserved for Future Use
Do not modify this field.
7
not_issued
WO
0
Force Event for Command Not Issued By Auto CMD12 Error
1: Interrupt is generated
0: No interrupt generated
6:5
-
WO
0
Reserved for Future Use
Do not modify field.
4
index
WO
0
Force Event for Auto CMD Index Error
1: Interrupt is generated
0: No interrupt generated
3
end_bit
WO
0
Force Event for Auto CMD End Bit Error
1: Interrupt is generated
0: No interrupt generated
2
crc
WO
0
Force Event for Auto CMD CRC Error
1: Interrupt is generated
0: No interrupt generated
1
to
WO
0
Force Event for Auto CMD Timeout Error
1: Interrupt is generated
0: No interrupt generated
0
not_excu
WO
0
Force Event for Auto CMD12 Not Executed
1: Interrupt is generated
0: No interrupt generated
Table 8-87: SDHC Force Event Register for Error Interrupt Status
Force Event Register for Error Interrupt Status
SDHC_FORCE_EVENT_INT_STAT
[0x0052]
Bits
Name
Access
Reset
Description
15:12
stat_vendor
R/W
0
Force Event for Vendor Specific Error Status
1: Interrupt is generated
0: No interrupt generated
