MAX32665-MAX32668 User Guide

Maxim Integrated Page 332 of 457

Figure 16-2: Continuous Mode Diagram

TMR_CN.TEN

TMR_CNT



0X0000_0000**

0X0000_0001*

TMR_INT.IRQ



TIMER CLOCK

TMR_CMP

* TMR_CNT AUTOMATICALLY RELOADS WITH 0X0000_0001 AT THE END OF THE TIMER PERIOD, BUT SOFTWARE CAN WRITE ANY INITIAL VALUE TO TMR_CNT

BEFORE THE TIMER IS ENABLE D.

** THE DEFAULT VALUE OF TMR_CNT FOR THE FIRST PE RIOD AFTER A SY STEM RESET IS 0X0000_0000 UNLESS CHANGED BY SOFTWARE.

SOFTW ARE CLEARS BIT

TMR_CN.TPL = 1

TMR_CN.TPL = 0

TIMER PIN

(OUTPUT)

0X0000_0002



SOFTWARE CLEARS BIT

 

  



16.5.1 Continuous Mode Timer Period

The timer period ends on the timer clock following TMRn_CNT = TMRn_CMP.
