Page #42 background image
MAX32665-MAX32668 User Guide
Maxim Integrated Page 42 of 457
Peripheral Register Name
Register Prefix
APB Base Address
APB End Address
Timer 1
TMR1_
0x4001 1000
0x4001 1FFF
Timer 2
TMR2_
0x4001 2000
0x4001 2FFF
Timer 3
TMR3_
0x4001 3000
0x4001 3FFF
Timer 4
TMR4_
0x4001 4000
0x4001 4FFF
Timer 5
TMR5_
0x4001 5000
0x4001 5FFF
HTimer 0
HTMR0_
0x4001 B000
0x4001 BFFF
HTimer 1
HTMR1_
0x4001 C000
0x4001 CFFF
I2C 0 (bus 0)
I2C0_BUS0_
0x4001 D000
0x4001 DFFF
I2C 1 (bus 0)
I2C1_BUS0_
0x4001 E000
0x4001 EFFF
I2C 2 (bus 0)
I2C2_BUS0_
0x4001 F000
0x4001 FFFF
SPIXF Master
SPIXF_
0x4002 6000
0x4002 6FFF
SPIXF Master Controller
SPIXFC_
0x4002 7000
0x4002 7FFF
Standard DMA 0
DMA0_
0x4002 8000
0x4002 8FFF
Flash Controller 0
FLC0_
0x4002 9000
0x4002 93FF
Flash Controller 1
FLC1_
0x4002 9400
0x4002 97FF
Instruction-Cache Controller 0
ICC0_
0x4002 A000
0x4002 A3FF
Instruction Cache Controller 1
ICC1_
0x4002 A800
0x4002 ABFF
Instruction Cache Controller XIP
SFCC_
0x4002 F000
0x4002 FFFF
External Memory Cache Controller
SRCC_
0x4003 3000
0x4003 3FFF
Analog to Digital Converter
ADC_
0x4003 4000
0x4003 4FFF
Standard DMA 1
DMA1_
0x4003 5000
0x4003 5FFF
Reserved
-
0x4003 6000
0x4003 6FFF
Reserved
-
0x4003 7000
0x4003 7FFF
SPIXR Master Controller
SPIXR_
0x4003 A000
0x4003 AFFF
Pulse Train Engine (bus 0)
PTG_BUS0_
0x4003 C000
0x4003 CFFF
1-Wire
OWM_
0x4003 D000
0x4003 DFFF
Semaphores
SEMA_
0x4003 E000
0x4003 EFFF
UART 0
UART0_
0x4004 2000
0x4004 2FFF
UART 1
UART1_
0x4004 3000
0x4004 3FFF
UART 2
UART2_
0x4004 4000
0x4004 4FFF
SPI1
SPI1_
0x4004 6000
0x4004 6FFF
SPI2
SPI2_
0x4004 7000
0x4004 7FFF
Audio Subsystem
AUDIO_
0x4004 C000
0x4004 CFFF
TRNG
TRNG_
0x4004 D000
0x4004 DFFF
BTLE Registers and IQ RAMs
BTLE_
0x4005 0000
0x4005 FFFF
I2C 0 (bus 1)
I2C0_BUS1_
0x4011 D000
0x4011 DFFF
I2C 1 (bus 1)
I2C1_BUS1_
0x4011 E000
0x4011 EFFF
I2C 2 (bus 1)
I2C2_BUS1_
0x4011 F000
0x4011 FFFF
Pulse Train Engine (bus 1)
PTG_BUS1_
0x4013 C000
0x4013 CFFF
3.5.2 AHB Peripheral Base Address Map
Table 3-2 contains the base address for each of the AHB mapped peripherals. The base address for a given peripheral is the
start of the register map for the peripheral. For a given peripheral, the address for a register within the peripheral is defined
as the AHB peripheral base address plus the registers offset.
