4.12 Single Inductor Multiple Output (SIMO) Registers
See Table 3-1: APB Peripheral Base Address Map for the SIMO Controller Peripheral Base Address.
Table 4-20: SIMO Controller Register Summary
Offset
Register
Name
[0x0004]
VREGO_A
Buck Voltage Regulator A Control Register
[0x0008]
VREGO_B
Buck Voltage Regulator B Control Register
[0x000C]
VREGO_C
Buck Voltage Regulator C Control Register
[0x0010]
VREGO_D
Buck Voltage Regulator D Control Register
[0x0014]
IPKA
Reserved
Reserved. Do not modify this field.
[0x0018]
IPKB
Reserved
Reserved. Do not modify this field.
[0x001C]
MAXTON
Reserved
Reserved. Do not modify this field.
[0x0020]
ILOAD_A
Reserved
Reserved. Do not modify this field.
[0x0024]
ILOAD_B
Reserved
Reserved. Do not modify this field.
[0x0028]
ILOAD_C
Reserved
Reserved. Do not modify this field.
[0x002C]
ILOAD_D
Reserved
Reserved. Do not modify this field.
[0x0030]
BUCK_ALERT_THR_A
Reserved
Reserved. Do not modify this field.
[0x0034]
BUCK_ALERT_THR_B
Reserved
Reserved. Do not modify this field.
[0x0038]
BUCK_ALERT_THR_C
Reserved
Reserved. Do not modify this field.
[0x003C]
BUCK_ALERT_THR_D
Reserved
Reserved. Do not modify this field.
[0x0040]
BUCK_OUT_READY
Buck Regulator Output Ready Register
[0x0044]
ZERO_CROSS_CAL_A
Reserved
Reserved. Do not modify this field.
[0x0048]
ZERO_CROSS_CAL_B
Reserved
Reserved. Do not modify this field.
