MAX32665-MAX32668 User Guide
Maxim Integrated Page 359 of 457
PT Resync Register
PTG_RESYNC
[0x0004]
Bits
Field
Access
Reset
Description
0
pt0
WO
-
Resync Control for PT0
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
Table 17-4:Pulse Train Engine Stopped Interrupt Flag Register
PT Stopped Interrupt Flag Register
PTG_INTFL
[0x0008]
Bits
Field
Access
Reset
Description
31:16
-
RO
0
Reserved for Future Use
Do not modify this field from its default value.
15
pt15
R/W1C
0
PT15 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
14
pt14
R/W1C
0
PT14 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
13
pt13
R/W1C
0
PT13 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
12
pt12
R/W1C
0
PT12 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
11
pt11
R/W1C
0
PT11 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
10
pt10
R/W1C
0
PT10 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
