MAX32665-MAX32668 User Guide
Maxim Integrated Page 411 of 457
USBHS Power Management
USBHS_POWER
[0x0001]
Bits
Name
Access
Reset
Description
0
suspendm
R/W
0
SUSPEND Mode Enable
0: SUSPEND Mode disabled. USB will not enter SUSPEND Mode.
1: SUSPEND Mode allowed. If no activity is detected on the bus for more than
3.0ms, this USB enters low-power SUSPEND Mode.
Table 21-8: USBHS IN Endpoint Interrupt Flags Register
USBHS IN Endpoint Interrupt Flags
USBHS_INTRINFL
[0x0002]
Bits
Name
Access
Reset
Description
16:12
-
ROC
0
Reserved for Future Use
Do not modify this field.
11
ep11_in
ROC
0
IN EP11 Interrupt Status Flag
0: IN Endpoint 11 not active.
1: IN Endpoint 11 occurred.
10
ep10_in
ROC
0
IN EP10 Interrupt Status Flag
0: IN Endpoint 10 not active.
1: IN Endpoint 11 occurred.
9
ep9_in
ROC
0
IN EP9 Interrupt Status Flag
0: IN Endpoint 9 not active.
1: IN Endpoint 9 occurred.
8
ep8_in
ROC
0
IN EP8 Interrupt Status Flag
0: IN Endpoint 8 not active.
1: IN Endpoint 8 occurred.
7
ep7_in
ROC
0
IN EP7 Interrupt Status Flag
0: IN Endpoint 7 not active.
1: IN Endpoint 7 occurred.
6
ep6_in
ROC
0
IN EP6 Interrupt Status Flag
0: IN Endpoint 6 not active.
1: IN Endpoint 6 occurred.
5
ep5_in
ROC
0
IN EP5 Interrupt Status Flag
0: IN Endpoint 5 not active.
1: IN Endpoint 5 occurred.
4
ep4_in
ROC
0
IN EP4 Interrupt Status Flag
0: IN Endpoint 4 not active.
1: IN Endpoint 4 occurred.
3
ep3_in
ROC
0
IN EP3 Interrupt Status Flag
0: IN Endpoint 3 not active.
1: IN Endpoint 3 occurred.
2
ep2_in
ROC
0
IN EP2 Interrupt Status Flag
0: IN Endpoint 2 not active.
1: IN Endpoint 2 occurred.
1
ep1_in
ROC
0
IN EP1 Interrupt Status Flag
0: IN Endpoint 1 not active.
1: IN Endpoint 1 occurred.
0
ep0
ROC
0
EP0 Interrupt Status Flag
0: In Endpoint 0 not active.
1: In Endpoint 0 occurred.
