Time-of-Day Alarm Interrupt Enable
Check the RTC_CTRL.busy flag after writing to this field to determine when the RTC
synchronization is complete.
0: Disable.
1: Enable.
*Note: Reset on POR only.
Real-Time Clock Enable
The RTC write enable (RTC_CTRL.write_en) bit must be set and RTC Busy
(RTC_CTRL.busy) must read 0 before writing to this field. After writing to this bit, check
theRTC_CTRL.busy flag for 0 to determine when the RTC synchronization is complete.
0: Disabled.
1: Enabled.
*Note: Reset on POR only.
Table 18-10. RTC 32KHz Oscillator Digital Trim Register
RTC 32KHz Oscillator Digital Trim
VRTC Time Counter
Hardware increments this field every 32s while the RTC is enabled.
*Note: Reset on POR only.
RTC Trim
This field specifies the 2s complement value of the trim resolution. Each increment or
decrement of the field adds or subtracts 1ppm at each 4kHz clock value with a
maximum correction of ± 127ppm.
*Note: Reset on POR only.
Table 18-11. RTC 32KHz Oscillator Control Register
Reserved for Future Use
Do not modify this field.
RTC Square Wave Output
0: Disabled.
1: Enables the 32kHz oscillator output or the external clock source is output on
square wave output pin. See Table 18-3. for configuration details.
*Note: Reset on POR only.
RTC Crystal Bypass
This field disables the RTC oscillator and allows an external clock source to be driven on
the 32KIN pin.
0: Disable bypass. RTC timebase is external 32kHz crystal.
1: Enable bypass. RTC timebase is external square wave driven on 32KIN.
*Note: Reset on POR only.
Reserved for Future Use
Software must not modify this field from its current value.
