MAX32665-MAX32668 User Guide
Maxim Integrated Page 224 of 457
9.2.2 DMA Source and Destination Addressing
The source and destination for DMA transfers are dictated by the request select dedicated to the peripheral instance. The
DMACHn_CFG.reqsel. field dictates the source and destination for a channel’s DMA transfer as shown in Table 9-2. The
DMACHn_SRC and DMACHn_DST registers hold the source and/or destination memory addresses, depending on the
specific operation.
The DMACHn_CFG.srcinc field is ignored when the DMA source is a peripheral memory, and the DMACHn_CFG.dstinc field
is ignored when the DMA destination is a peripheral memory.
Table 9-2: MAX32665—MAX32668 DMAC Source and Destination by Peripheral
