MAX32665-MAX32668 User Guide

Maxim Integrated Page 305 of 457

I2C DMA

I2Cn_DMA

[0x0048]

Bits

Field

Access

Reset

Description

rxen

R/W

RX DMA Channel Enable

0: Disable

1: Enable

txen

R/W

TX DMA Channel Enable

0: Disable

1: Enable

Table 13-24: I

C Slave Address Register

C Slave Address

I2Cn_SLV_ADDR

[0x004C]

Bits

Field

Access

Reset

Description

31:16

Reserved

R/W

Slave Mode Extended Address Length Select

0: 7-bit addressing.

1: 10-bit addressing.

14:10

Reserved

9:0

sla

R/W

Slave Mode Slave Address

In Slave Mode Operation, (I2Cn_CTRL0.mstr = 0), set this field to the slave address

for the I2Cn port. For 7-bit addressing, the address occupies the least significant 7

bits. For 10-bit addressing, the 9-bits of address occupies the most significant 9 bit

and the R/W bit occupies the least significant bit.

Note: I2Cn_SLV_ADDR.ea controls if this field is a 7-bit or 10-bit address.
