MAX32665-MAX32668 User Guide

Maxim Integrated Page 348 of 457

Table 16-6: Timer Non-Overlapping Compare Registers

Timer Non-Overlapping Compare Register

TMRn_NOLCMP

[0x0014]

Bits

Name

Access

Reset

Description

31:16

Reserved for Future Use

Do not modify this field from its default value.

15:8

nolhcmp

R/W

Non-Overlapping High Compare

The 8-bit timer count value of non-overlapping time between the falling edge of PWM

output 



󰆓

and the next rising edge of PWM output 



7:0

nollcmp

R/W

Non-Overlapping Low Compare

The 8-bit timer count value of non-overlapping time between the falling edge of PWM

output 



and next rising edge of PWM output 



󰆓
