PT Resync Register
PTG_RESYNC
[0x0004]
Bits
Field
Access
Reset
Description
5
pt5
WO
-
Resync Control for PT5
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
4
pt4
WO
-
Resync Control for PT4
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
3
pt3
WO
-
Resync Control for PT3
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
2
pt2
WO
-
Resync Control for PT2
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
1
pt1
WO
-
Resync Control for PT1
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
