MAX32665-MAX32668 User Guide
Maxim Integrated Page 357 of 457
PT Resync Register
PTG_RESYNC
[0x0004]
Bits
Field
Access
Reset
Description
10
pt10
WO
-
Resync Control for PT10
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
9
pt9
WO
-
Resync Control for PT9
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
8
pt8
WO
-
Resync Control for PT8
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
7
pt7
WO
-
Resync Control for PT7
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
6
pt6
WO
-
Resync Control for PT6
Write 1 to reset the output of the pulse train. For pulse train mode the output is
restarted to the beginning of the output pattern. For Square Wave mode the output is
reset to 0.
Setting multiple bits simultaneously in this register synchronizes the set outputs.
1: Reset/restart the pulse train
0: No effect
Note: Writing 1 has no effect if the corresponding pulse train is disabled.
