MAX32665-MAX32668 User Guide
Maxim Integrated Page 360 of 457
PT Stopped Interrupt Flag Register
PTG_INTFL
[0x0008]
Bits
Field
Access
Reset
Description
9
pt9
R/W1C
0
PT9 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
8
pt8
R/W1C
0
PT8 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
7
pt7
R/W1C
0
PT7 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
6
pt6
R/W1C
0
PT6 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
5
pt5
R/W1C
0
PT5 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
4
pt4
R/W1C
0
PT4 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
3
pt3
R/W1C
0
PT3 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
2
pt2
R/W1C
0
PT2 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
1
pt1
R/W1C
0
PT1 Stopped Status Flag
This bit is set to 1 by hardware when the corresponding pulse train is in Pulse Train
Mode and the loop counter reaches 0. In Square Wave mode, this field is not used.
Write 1 to clear.
1: Pulse Train is stopped.
