ADC Limit 0
ADC_LIMIT0
[0x0010]
ADC Limit 1
ADC_LIMIT1
[0x0014]
ADC Limit 2
ADC_LIMIT2
[0x0018]
ADC Limit 3
ADC_LIMIT3
[0x001C]
Bits
Field
Access
Reset
Description
23:22
-
RO
0
Reserved for Future Use
Do not modify this field.
21:12
ch_hi_limit
R/W
0x3FF
High Limit Threshold
Sets the threshold for high-limit comparisons. This field is a 10-bit value compared
against any ADC conversion on the channel set in the ch_sel field. ADC conversions
greater than this field are over threshold and can result in interrupt assertion if the
ch_hi_limit_en field is set.
Valid values for this field are 0x000 to 0x3FF.
11:10
-
RO
0
Reserved for Future Use
Do not modify this field.
9:0
ch_lo_limit
R/W
0
Low Limit Threshold
Sets the threshold for low-limit comparisons. This field is a 10-bit value compared
against any ADC conversion on the channel set in the ch_sel field. ADC conversions
less than this field are under threshold and can result in interrupt assertion if the
ch_lo_limit_en field is set.
Valid values for this field are 0x000 to 0x3FF.
