MAX32665-MAX32668 User Guide

Maxim Integrated Page 368 of 457

Pulse Train Automatic Restart Configuration

PTn_RESTART

[0x002C]

Bits

Field

Access

Reset

Description

on_pt_n_loop

_exit

R/W

Enable Automatic Restart for this Pulse Train on a PTn Stop Event

0: Disable automatic restart

1: When PTn has a Stop Event, automatically restart pulse train from the beginning of

its pattern.

6:5

Reserved for Future Use

Do not modify this field from its default value.

4:0

pt_n_select

R/W

Select PTn

Select the pulse train number to be associated with PTn. This engine must be in pulse

train mode.

0b00000: PT0

0b00001: PT1

0b00010: PT2

0b00011: PT3

0b00100: PT4

0b00101: PT5

0b00110: PT6

0b00111: PT7

0b01000: PT8

0b01001: PT9

0b01010: PT10

0b01011: PT11

0b01100: PT12

0b01101: PT13

0b01110: PT14

0b01111: PT15

0b1xxxx: Reserved.
