MAX32665-MAX32668 User Guide
Maxim Integrated Page 49 of 457
Error Correction Coding Address
ECC Error Address/DATA RAM Error Address
Data depends on which block has reported the error. If sysram, fl0, or fl1, then
this bit(s) represents bit 15 of the AMBA address of read which produced the
error. If the error is from one of the caches, then this bit is set as shown below:
0: No Error
1: DATA RAM Error. The error is in the Data RAM
ECC Error Address/DATA RAM Error Bank
Data depends on which block has reported the error. If sysram, fl0, or fl1, then
this bit(s) represents bit 14 of the AMBA address of read which produced the
error. If the error is from one of the caches, then this bit is set as shown below:
0: Error is in DATA RAM Bank 0
1: Error is in DATA RAM Bank 1
ECC Error Address/TAG RAM Error Address
Data depends on which block has reported the error. If sysram, fl0, or fl1, then
this bit(s) represents bits 13:0 of the AMBA address of read which produced the
error. If the error is from one of the caches, then this bit is set as shown below:
[DATA ADDRESS]: Represents the DATA RAM Error Address
