23.3.6 Viewing History
• The History > Session window is shown in network view, node view, and card view. It shows alarms
and conditions that occurred during the current user CTC session.
• The History > Node window is only shown in node view. It shows the alarms and conditions that
occurred on the node since CTC software was operated on the node.
• The History > Card window is only shown in card view. It shows the alarms and conditions that
occurred on the card since CTC software was installed on the node.
Tip Double-click an alarm in the History window to display the corresponding view. For example,
double-clicking a card alarm takes you to card view. In network view, double-clicking a node alarm takes
you to node view.
If you check the History window Alarms check box, you display the node history of alarms. If you check
the Events check box, you display the node history of Not Alarmed and transient events (conditions). If
you check both check boxes, you retrieve node history for both.
23.3.6.1 History Column Descriptions
Table 23-4 lists the History window column headings and the information recorded in each column.
Table 23-4 History Column Description
Column Information Recorded
Num Num (number) is the quantity of alarm messages received, and is incremented
automatically as alarms occur to display the current total of received error messages.
(The column is hidden by default; to view it, right-click a column and choose Show
Column.)
Ref Ref (reference) is a unique identification number assigned to each alarm to reference a
specific alarm message that is displayed. (The column is hidden by default; to view it,
right-click a column and choose Show Column.)
Date Date and time of the condition.
Object TL1 AID for the condition object. For an STSmon or VTmon, the object.
Slot Slot where the condition occurred (only displays in network view and node view).
Port Port where the condition occurred. For STSTerm and VTTerm, the port refers to the
upstream card it is partnered with.
Path Width Width of the data path.
Sev Severity level: Critical (CR), Major (MJ), Minor (MN), Not Alarmed (NA),
Not Reported (NR).
ST Status: raised (R), cleared (C), or transient (T).
SA Indicates a service-affecting alarm (when checked).
Cond Condition name.
Description Description of the condition.
Eqpt Type Card type in this slot.
