5-53
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G231 Change Section Trace Settings for TXP_MR_2.5G and TXPP_MR_2.5G Cards
DLP-G231 Change Section Trace Settings for TXP_MR_2.5G and
TXPP_MR_2.5G Cards
Note This task only applies to SONET services.
Step 1 In node view, double-click the TXP_MR_2.5G or TXPP_MR_2.5G card where you want to change the
section trace settings.
Step 2 Click the Provisioning > Line > Section Trace tabs.
Step 3 Modify any of the settings described in Table 5-31.
Purpose This task changes the section trace settings for TXP_MR_2.5G and
TXPP_MR_2.5G transponder cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-31 TXP_MR_2.5G and TXPP_MR_2.5G Transponder Card Section Trace Settings
Parameter Description Options
Port (Display only) Port number.
• 1
• 2
• 3 (TXPP_MR_2.5G only)
Trace Mode Sets the trace mode.
• Off/None
• Manual
Section Trace
String Size
Sets the trace string size.
• 1 byte
• 16 byte
Transmit Displays the current transmit string; sets
a new transmit string. You can click the
button on the right to change the display.
Its title changes, based on the current
display mode. Click Hex to change the
display to hexadecimal (button changes to
ASCII); click ASCII to change the
display to ASCII (button changes to Hex).
String of trace string size
