9-19
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 9 Monitor Performance
NTP-G75 Monitor Transponder and Muxponder Performance
Step 4 Click Refresh. Optical line power statistics for the selected port appear.
Step 5 Click the Optical Band tab.
Step 6 In the Port drop-down list, choose an optical band port (Table 9-4) where you want to view the optical
power statistics.
Step 7 Click Refresh. Optical channel PM statistics for the selected port appear.
Step 8 Return to your originating procedure (NTP).
NTP-G75 Monitor Transponder and Muxponder Performance
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the node that you want to monitor. If you
are already logged in, continue with Step 2.
Table 9-4 Band OADM Optical Line Ports
Port Name
Port Number
AD-1B-xx.x AD-4B-xx.x
BAND RX 1 1
BAND TX 2 2
BAND RX — 3
BAND TX — 4
BAND RX — 5
BAND TX — 6
BAND RX — 7
BAND TX — 8
Purpose This procedure enables you to view node near-end or far-end
performance during selected time intervals on a transponder
(TXP_MR_10G, TXP_MR_2.5G, TXPP_MR_2.5G, TXP_MR_10E) or
muxponder (MXP_2.5G_10E, MXP_MR_2.5G, MXPP_MR_2.5G,
MXP_2.5G_10G) card and port to detect possible performance problems.
Tools/Equipment None
Prerequisite Procedures Before you monitor performance, be sure you have created the
appropriate circuits and provisioned the card according to your
specifications. For more information, see Chapter 7, “Create Channels
and Circuits,” Chapter 5, “Provision Transponder and Muxponder
Cards,”or Chapter 11, “Change DWDM Card Settings.”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
