11-2
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 11 Change DWDM Card Settings
NTP-G90 Modify OSCM and OSC-CSM Line Settings and PM Parameters and Thresholds
NTP-G90 Modify OSCM and OSC-CSM Line Settings and PM
Parameters and Thresholds
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the node where you want to change the
OSCM or OSC-CSM card settings. If you are already logged in, proceed to Step 2.
Step 2 Complete the “NTP-G103 Back Up the Database” procedure on page 13-2.
Step 3 Perform any of the following tasks as needed:
• DLP-G199 Change the OSCM and OSC-CSM Optical Service Channel Settings, page 11-2
• DLP-G200 Change the OSCM and OSC-CSM Optical Service Channel Thresholds, page 11-5
• DLP-G201 Change Optical Line Parameters for OSCM and OSC-CSM Cards, page 11-6
• DLP-G202 Change the OSCM and OSC-CSM Optical Line Threshold Settings, page 11-8
• DLP-G203 Change the OSCM and OSC-CSM ALS Maintenance Settings, page 11-10
Step 4 Complete the “NTP-G103 Back Up the Database” procedure on page 13-2.
Stop. You have completed this procedure.
DLP-G199 Change the OSCM and OSC-CSM Optical Service Channel Settings
Step 1 In node view, double-click the OSCM or OSC-CSM card where you want to change the OC-3 optical
line settings.
Step 2 Click the Provisioning > OC3 Line > OC3 Line tabs.
Step 3 Modify any of the settings described in Table 11-1. The provisionable parameters are listed in the
Options column in the table.
Purpose This procedure changes the optical service channel (OC-3/STM-1) and PM
parameters and thresholds for the OSCM and OSC-CSM cards.
Tools/Equipment None
Prerequisite Procedures NTP-G30 Install the DWDM Cards, page 3-39
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Purpose This task changes the OC-3/STM-1 optical service channel settings for
OSCM and OSC-CSM cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
