15-35
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 15 Shelf Hardware Reference
15.10 Filler Card
15.10 Filler Card
The filler card is designed to occupy empty multiservice and AIC-I slots in the Cisco ONS 15454
(Slots 1 – 6, 9, and 12 – 17). The filler card cannot operate in the XC slots (Slots 8 and 10) or TCC slots
(Slots 7 and 11). The filler card is detected by CTC.
When installed, the filler card aids in maintaining proper air flow and EMI requirements.
Figure 15-34 shows the card faceplate. The filler card has no card-level LED indicators.
5 COM_3 31 —
6 NO_3 32 NO_4
7— 33COM_4
8 COM_5 34 —
9 NO_5 35 NO_6
10 — 36 COM_6
11 COM_7 37 —
12 NO_7 38 NO_8
13 — 39 COM_8
14 COM_9 40 —
15 NO_9 41 NO_10
16 — 42 COM_10
17 COM_11 43 —
18 NO_11 44 NO_12
19 — 45 COM_12
20 COM_13 46 —
21 NO_13 47 NO_14
22 — 48 COM_14
23 COM_15 49 —
24 NO_15 50 —
25 — 51 GND1
26 NO_0 52 GND2
Table 15-8 Pin Association for Alarm Output Pins (continued)
AMP Champ
Pin Number Signal Name
AMP Champ
Pin Number Signal Name
