10-15
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 10 Manage the Node
DLP-G294 Edit the OSI Router Configuration
• Intermediate System Level 1/Level 2—The ONS 15454 performs IS functions. It communicates
with IS and ES nodes that reside within its OSI area. It also communicates with IS L1/L2 nodes that
reside in other OSI areas. Before choosing this option, verify the following:
–
The node is connected to another IS Level 1/Level 2 node that resides in a different OSI area.
–
The node is connected to all nodes within its area that are provisioned as IS L1/L2.
Note Changing a routing mode should be carefully considered. Additional information about OSI ESs
and ISs and the ES-IS and IS-IS protocols are provided in Chapter 22, “Management
Connectivity Reference.”
Step 4 Although Cisco does not recommend changing the LSP buffer sizes, you can adjust the buffers in the
following fields:
• L1 LSP Buffer Size—Adjusts the Level 1 link state PDU buffer size.
• L2 LSP Buffer Size—Adjusts the Level 2 link state PDU buffer size.
Step 5 Return to your originating procedure (NTP).
DLP-G294 Edit the OSI Router Configuration
Step 1 Click the Provisioning > OSI > Routers > Setup tabs.
Step 2 Choose the router you want provision and click Edit.
Step 3 In the OSI Router Editor dialog box:
a. Check or uncheck the Enabled box to enable or disable the router.
Note Router 1 must be enabled before you can enable Routers 2 and 3.
b. For enabled routers, edit the primary area address, if needed. The address can be between
8 and 24 alphanumeric characters in length.
c. If you want to add or edit an area address to the primary area, enter the address at the bottom of the
Multiple Area Addresses area. The area address can be 2 to 26 numeric characters (0–9) in length.
Click Add.
d. Click OK.
Purpose This task allows you to edit the OSI router configuration, including
enabling and disabling OSI routers, editing the primary area address, and
creating or editing additional area addresses.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
